RCV

The SEVA (Smart Electric Valve Actuator) is an electric actuator featuring a microprocessor-controlled linear stepper motor, designed to respond to various control inputs. It offers optional isolated loop-powered position output for signaling back to an indicator or control panel, making it suitable for applications in aviation, aerospace, petrochemical, refining, chemical metering, oil and gas, and industrial test equipment.

The Badger Meter Type 807 is a compact, low-flow control valve designed for precise modulation of liquids, gases, or steam in applications where space and accuracy are critical. Available in sizes from ¼" to 1", it handles pressures up to 5,000 PSI and temperatures up to 1,200°F, making it ideal for additive injection, sampling, and pilot plant operations. Its features include interchangeable trim sets, a threaded bonnet for easy maintenance, and ANSI Class IV shutoff, ensuring reliability and versatility in demanding environments.

The Badger Meter Type 860 and Type 809 are compact, ½-inch globe control valves designed for precise modulation of medium to low flow rates in industrial applications. Both models feature ANSI Class 150 raised face flanges, interchangeable trim sets with various flow characteristics (linear, equal percent, quick open, or double taper), and TFE chevron packing for reliable sealing. The Type 860 is tailored for standard flange sizes, while the Type 809 offers additional flange sizes and pressure ratings, providing versatility to meet specific piping requirements

The Badger Meter Research Control Valve Model 9000 Flange Control Valve is a compact, ANSI Class 300 globe valve ideal for modulating control of liquids and vapors in medium-duty industrial applications. Available in 1" to 2" sizes, it features raised-face ANSI flanges socket-welded to the body—with concentric serrations for superior gasket sealing. Constructed with thick-walled 316 stainless steel or Alloy C, it handles temperatures from 100 °F to 1000 °F (38 °C to 538 °C) while offering high-performance, reliable control in demanding process environments.

Badger Meter offers the RCV PVDF Plastic Control Valve—specifically engineered for corrosive-service applications where traditional materials fall short. Available in compact sizes (¼", ½", ¾", and 1"), this lightweight valve handles low to medium flow rates with excellent chemical resistance and corrosion safety. It delivers reliable, precise control in environments such as pH regulation, chemical feed, water treatment, pilot plants, semiconductor processing, and pulp and paper operations.
